RECON-F4
Integrations
Technical Specifications
Sensor Precision:
5 mm One sigma @ 100 m
RMSEz Accuracy:
2-3.5
Max AGL @ 20% Ref.:
360m
Laser Wavelength:
1535nm
Laser Scanner:
-
Field of View:
80°
Max Echoes:
≤ 7
PRR:
550 kHz
Scan Rate:
30 - 300 lines/second
Weight:
1.3kg
Dimensions:
17.5 x 11.4 x 10.3 cm
Voltage/ Power:
13.7 - 32.0 V DC
Operating Temps:
-20° to +50°C (-4° to +122°F)
Beam Divergence:
0.5 mrad @ 1/e
RMSDz Precision:
2.5 cm RMSDz @ 120 m
NDAA Compliant:
-
RFM2
5 mm
2.0 cm @ 120 m
490m
1550nm
Riegl VUX 1 UAV22
360° x2
15
2400 kHz
10 - 200 lines/second x2
17.4kg
43.2 x 53.3 x 22.8 cm
14-28 VDC / 180 W
0 - +40° C
0.35 mrad @ 1/e
2.0 cm @ 120 m
-
