RFM2
Integrations
Vehicle
Technical Specifications
Sensor Precision:
5 mm
RMSEz System Accuracy:
2.0 cm @ 120 m
Max AGL @ 20% Reflectivity:
490m
Laser Wavelength:
1550nm
Laser Scanner Model:
Riegl VUX 1 UAV22
Field of View:
360° x2
Max Echoes/ Returns per pulse:
15
Pulse Repetition Rate (PRR):
2400 kHz
Scan Rate:
10 - 200 lines/second x2
Weight:
17.4kg
Dimensions:
43.2 x 53.3 x 22.8 cm
Operating Voltage/ Power:
14-28 VDC / 180 W
Operating Temps:
0 - +40° C
Beam Divergence:
0.35 mrad @ 1/e
Constellation Support:
GPS, GLONASS, BEIDOU, GALILEO
RMSDz Instraswath Precision:
2.0 cm @ 120 m
ULTRAPOD UP1
Airplane
15 mm
2.5-5 cm @ 350 m
900m
1550nm
Riegl VUX 240
75°
15
1800 kHz
40 - 400 lines/second
22kg
35.2 x 16.4 x 18.5 cm
14-28 VDC / 75 W (max)
0 - +40° C
0.35 mrad
GPS, GLONASS, BEIDOU, GALILEO
N/A
